The 2026 Trek Rail+ 9.8 GX AXS T-Type Gen 5 800Wh Electric Full Suspension Carbon MTB In Deep Smoke Small 15.5 inch Deep Smoke is available at the following locations.
The item will be transferred to the location you choose during checkout.
If the item is not currently available to view at your desired location, please call your nearest store to arrange for it to be transferred.
The Rail+ 9.8 is a carbon enduro e-MTB made for chasing after distant peaks and hammering out laps. With 160 mm front and rear travel, it's ready to rip through the rough, and it's backed by a powerful Bosch Performance CX drive system that makes long climbs and fast laps a breeze. It packs in adjustable geometry that lets you customise your bike for how and where you ride, a massive battery that keeps you going lap after lap, and a SRAM GX AXS wireless transmission for crisp shifts under load.
You chase big rides with even bigger terrain and need an e-bike that can keep up. You want plenty of suspension for gobbling up roots and rocks and a full-assist motor that doesn't wallow on punchy climbs. You care about upgrades where they matter most, like a carbon frame, upgraded suspension package and fully wireless SRAM transmission.
An OCLV Mountain Carbon frame with Bosch Performance CX system (85Nm, 250W) and a massive 800Wh RIB 2.0 removable integrated battery. A 160mm RockShox ZEB Select+ fork with DebonAir spring and Charger 3 RC2 damper, and RockShox Super Deluxe Select+ rear shock. Tubeless Ready Bontrager Line Comp 30 wheels, a wireless SRAM GX AXS transmission, 4-piston SRAM CODE Bronze hydraulic disc brakes and an internally-routed dropper post.
The Rail+ 9.8 is ready for epic rides that take you far beyond the beyond. With plenty of travel for rowdy terrain, a powerful motor for crushing big climbs, and a massive battery that keeps you going mile after mile, this beast of a bike is built for it all.
Bosch Performance Line CX motor
The Bosch Performance Line CX sets the standard for eMTB performance with up to 85 Nm of torque and an intelligent eMTB mode with Extended Boost that automatically adjusts the amount of assist based on the terrain.
New RIB 2.0
Removable Integrated Battery (RIB 2.0) makes it easy to remove your battery for more convenient charging or travelling, and you don't have to worry about dropping it thanks to a secondary safety catch.
Mixed wheel size
You get a 29"" front wheel for monster truckin' over stuff, with a smaller 27.5"" wheel out back for getting rowdy.
Adjust the suss for full send
Adjust the leverage rate with just a flip of a chip. Ride it in the Less progressive setting for a plusher feel perfect for rugged trails with square-edge bumps. Flip it to More progressive when you're hitting big features and don't want to bottom-out, or when you want to run a coil shock.
Transition to transmission
The SRAM Eagle T-Type transmission mounts directly to the frame, skipping that pesky derailleur hanger of yesteryear. This makes for a more robust system that's not only cleaner-looking, it's also more precise under load and easier to set up.
Bosch System Controller
The System Controller gives you a quick overview of your assist mode and battery level without distracting you from the ride. It's integrated into the top tube so it's out of the way but still easy to see with LED indicators. It also connects to the eBike Flow app via Bluetooth for accessing ride stats and performing system updates.
Click & Collect
For Click & Collect orders, for security you must present photo ID plus the payment card used at time of collection. This is also applicable when you have purchased using V12 Finance. For more information click HERE
Parts & Accessories
Place an order for £50 or more and delivery is free to mainland UK (including Highlands), for an order under £50 delivery is charged at £8.99.
For Highlands, Northern Ireland, Isle Or Man and other non mainland locations additional charges will apply. For parts and accessories we aim to despatch the next working day after the order is placed.
For hygiene and safety reasons, helmets cannot be returned or exchanged unless they are faulty. Please ensure you choose the correct size and style before purchasing.
Delivery With Multiple Items On Order
Please note if you order more than one item online your products may arrive in separate shipments. We do aim to send everything together but logistically this is sometimes just not feasible. For more information about delivery timescales please click HERE
Lead Times Electric Bikes
Before despatch, bikes are built, configured and tested by one of our experienced technical team.
We aim to despatch an in-stock bike 1-5 days after an order is placed (not including weekends / bank & public holidays). For bike located in a warehouse location we aim to dispatch within 10-12 days (not including weekends / bank & public holidays).
Please note the dispatch timescale shown in on our website / basket / order confirmation are estimated. If applicable Saturdays are included in the calculation however items are normally only dispatched Monday to Friday.
Bikes will be delivered by DX or TNT, please for some models the front wheel will be packed in a separate box but both wheel and bike should be delivered at the same time.
On all boxed deliveries the product name on the box may not match the model inside (our team sometimes have to use a different box than the one that initially came from the manufacturer) so please open the box to check!
Please note that Cube Stereo models are not supplied with pedals, browse our range HERE
Boxed Bike Delivery
Free boxed delivery requires basic assembly of your bike when it arrives. Generally the front wheel will need to be reattached, the bars will need to be turned plus pedals fitted.
Watch Our Video To Show How To Assemble Your Bike From The Box HERE
FREE boxed bike delivery Our Standard Boxed Delivery for bikes is FREE to UK mainland locations (excluding Highlands where there is an additional surcharge payable).
We can also deliver a bike to BT Northern Ireland and IM Isle Of Man subject to surcharges plus Orkney and Shetland Islands, please refer to the map below for our current prices, for other non mainland locations please contact us for a quote.
Ready2Ride Delivery
Choose our Ready2Ride Service and one of our team will deliver your new bike, fully built, configured and tested, we will personally hand over your new bike, make adjustments if required and can also wait while you take a short test ride round the block. If your postcode qualifies for this service it will be available to select at checkout. If your delivery address is outside our delivery area please contact our Customer Services team on 0117 452 6571
Ready2Ride Delivery For Cargo Bikes
From mid July 2024 we are now able to deliver a cargo bike in a box for FREE (to our regular FREE delivery areas - not Highlands etc)
Previously as our cargo bikes are larger than standard electric bikes they were only available for home delivery via our Ready2Ride delivery option (or click and collect), you can still select this option however if you prefer. One of our team will deliver your new bike, fully built, configured and tested, we will personally hand over your new bike, make adjustments if required and can also wait while you take a short test ride round the block.
This premium delivery is available to locations within a 50-75 miles radius of one of our stores. If your postcode qualifies for this service it will be available to select at checkout. If your delivery address is outside our delivery area please contact our Customer Services team on 0117 452 6571
We accept vouchers from Cyclescheme, Cycle2Work (also known as Halfords Cycle2Work), Bike2Work, Cycle Solutions, Caboodle, Dash, Green Commute Initiative, Gogeta, My Benefits World & Vivup.
Find out more on our Cycle to Work page HERE
If you need a quote, you can save your basket as a quote at the checkout, or get in touch by phone, email or via our Live Chat and one of our team will send you a quote by email.
CycleScheme vouchers can be used when purchasing online, select ‘payment’ option in checkout and provide your voucher number and redemption code. Our team will then be in contact and will process your voucher.
To purchase a bike via Cycle2Work, Bike2Work, Cycle Solutions, Caboodle, Dash Rides, Green Commute Initiative, Gogeta, My Benefits World & Vivup please contact our Customer Services Team on 0117 452 6571 and we will process your order manually.
Service Plans are available on all bikes purchased in store and online within 60 days of purchase and a great way to save money on future services.
Your Service Plan is non-refundable, non-transferable and is registered to you and your bike (frame number required)
To ensure that we never let our you down, we proactively monitor competitor prices and adjust our own prices every week.
However, if you do find a product online for less than the price offered on our website or in store, please get in touch and we may be able to match it, as long as it matches the criteria below.
If you want to request a price match from us, simply contact our customer service team on 0117 452 6571 or contact us via our live chat.
| E-Bike System | |
| Motor | Bosch Performance Line CX Gen 5, 15.5mph, 85Nm torque |
| Display / Controller | Bosch System Controller BRC3100, smart system |
| Battery | Bosch PowerTube 800Wh, Removable Integrated Battery (RIB 2.0) |
| Charger | Bosch standard 4A, 230V, smart system |
| Frame | |
| Frame | OCLV Mountain Carbon main frame, tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9mm seat tube, ABP, UDH Boost148, 12mm thru axle, 160mm travel |
| Fork | Fox Performance Elite Float 38, Float EVOL air spring, GRIP X damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt-X axle, 160mm travel |
| Rear shock | Fox Performance Elite Float X, 2-position damper, 205mm x 65mm |
| Drivechain and Brakes | |
| Brakes | SRAM CODE Bronze 4-piston hydraulic disc (200mm front / 220mm rear) |
| Crankset | SRAM GX, 160mm length |
| Rear derailleur | SRAM GX Eagle AXS, T-Type |
| Shifters | SRAM AXS POD |
| Cassette | SRAM Eagle XS-1275, T-Type, 10-52, 12-speed |
| Chain | SRAM GX Eagle, T-Type, 12-speed |
| Cockpit | |
| Handlebar | Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 780mm width |
| Grips | Bontrager XR Trail Elite, nylon lock-on |
| Stem | Bontrager Line Pro, 35mm, Blendr-compatible, 0-degree, 45mm length |
| Saddle | Verse Short Comp, steel rails, 145mm width |
| Seatpost | Bontrager Line Dropper, MaxFlow, internal routing, 34.9mm (150mm - 200mm travel depending on size) |
| Wheels | |
| Front wheel | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle (27.5" or 29" depending on size) |
| Rear wheel | Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 27.5" |
| Tyres | Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5x2.50" or 29x2.50" |
| Accessories | |
| Pedals | VP-536 nylon platform |
| Mudguards | Trek 27.5" custom mudguard |
| Miscellaneous | |
| Maximum system weight | 136kg (300 lb) |
| Weight | Size M: 24.18kg / 53.31 lb (with TLR sealant, no tubes) |
| Colours | Deep Smoke |
| Sizes | Large 19.5 inch, Medium 17.5 inch, Small 15.5 inch, X-Large 21.5 inch |
| Brand | Trek |
| Model Year | 2026 |
| Barcodes | 197216100539, 197216100546, 197216100553, 197216100560 |
| SKUs / Part Numbers | 5329081, 5329082, 5329083, 5329084 |
Please note: Manufacturers can sometimes change the specification of the products from time to time.
